Drying Machine KS series

Feature ( KS-001R )

• KS-001R uses only water absortion roll. Body is designed compactly so as to be installed into even a small space.
• As for a standard machine the entrance is work table and exit is chute, but conveyer can be adopted at option.
• The double water absorption rolls are installed for thorough absorption.
• According to thickness of products in the bag, water absorption roll can be adjusted easily.

Feature ( KS-001 )

• Products placed on the net conveyor made from stainless steel automatically go through the water absortion roll and the warm air tunnel. The efficient in drying is substancially risen.
• The warm air tunnel has semi-closure structure ,and the net conveyer made from stainless steel is adopted, which enable to dry also the bag bottom.
• Special water absorption roll always looses moisture on the squeeze roll. The water absorption capability is not reduced, even if it is used for long time continuously.
• The speed of the conveyer can be easily adjusted with the handle.
• The water absorption roll is frexible, and even a bag with thickness of about 10cm can be used.

Feature ( KS-004 )

• KS-001 is enlarged in the dimension to handle a lot of bags.
• The double water absorption roll are adopted, and the speed of the conveyer can be risen.
